Stainless Steel Wire Mesh

Material: stainless steel wire SS201,202,302,304,304L,316,316L

Weaving patterns involved: plain weave, twill weave and Dutch weave.

· Roll width: 1m,1.2m,1.5m,2m.

· Roll length: 25m, 30m,40m,50m.

Features:Acid resistant,alkali resistant,heart resistant,corrosion resistant.

Roll sizes:Standard roll width: 1m-2m, Standard roll length: 30m-50m.

Application: used for separation of solids and clear filtration of liquids, cleaning of fuels or hydraulic liquids, or in water treatment,agriculture, building, communication and transportation and mineral extraction.

Mesh	Wire diameter（mm）	aperture（mm）
150	0.07	0.0993
165	0.058	0.0959
180	0.058	0.0831
200	0.058	0.0690
225	0.05	0.0690
235	0.045	0.0631
250	0.04	0.0616
270	0.04	0.0541
280	0.04	0.0507
300	0.035	0.0497
300	0.038	0.0467
300	0.04	0.0447
315	0.035	0.0456
325	0.035	0.0432
350	0.035	0.0376
350	0.03	0.0426
363	0.03	0.0400
400	0.025	0.0385
400	0.028	0.0355
400	0.03	0.0335
450	0.025	0.0314
500	0.025	0.0258
510	0.025	0.0248
530	0.024	0.0239
635	0.018	0.022
635	0.02	0.02
